Workflow agents

A workflow agent connects nodes to configure conditions, loops, parallel work, and human input. Select Workflow mode under Create agent, then build an execution path from start inputs to end outputs.

Screenshot TODO

Capture the workflow builder with Start, Condition, Tool Call, and End nodes and the properties panel on the right.

Basic workflow

1. In the Start node, define each input variable's name, type, required state, default value, and description.
2. Drag a node from the palette, or drop an output connector onto empty canvas and select the next node.
3. Select the node and configure its inputs, outputs, and execution options in the properties panel on the right.
4. In the End node, map the output names, types, and values to return.
5. Save the workflow, then select Deploy.

Map a node output to a later node input by using a nodeName.field value reference. Use the output picker in the properties panel to reduce typing errors.

Main settings by node

Node	Settings and result
Start	Declare execution input variables.
End	Map final output names, types, and values.
Agent	Configure instructions, a registered model, tools and actors, and maximum iterations.
LLM	Configure the model, reasoning effort, prompt and system prompt, and output variables.
Code	Configure Python or JavaScript source, input mappings, and a timeout. Data-connection and RAG code insertion are available.
Template	Render template content and save it to an output variable.
Variable	Apply set, append, merge, increment, decrement, and delete operations in order.
Tool Call	Configure a tool, input mappings, and a timeout.
Actor Call	Configure an actor, input mappings, a timeout, and an auto / confirm / deny confirmation policy.
Condition	Evaluate an expression and split the flow into true and false connectors.
Loop	Configure list or count mode, a source and iterator or count and counter, and maximum iterations.
Parallel	Configure branches, an all / any join mode, and a timeout.
User Input	Configure instructions, input fields, and a timeout. Select approve, reject, or error as the timeout result.
Error Handler	Configure the target node, retry count and interval, fixed or exponential backoff, and fallback, skip, or stop behavior.

Branches and termination conditions

• Connect the Condition node's true and false connectors to their respective next nodes.
• Connect nodes to repeat through the Loop body path and connect the next path to the node that runs after the loop. Set maximum iterations to prevent an infinite run.
• In Parallel, all waits for every branch and any joins after one branch completes. Set a timeout as well.
• Separate the success and fallback paths from an Error Handler. If no fallback runs, review whether the result is skip or stop the entire workflow.

Connection constraints

The following connections cannot be created.

• A connection from a node back to itself
• A connection into the Start node
• A connection out of the End node
• A duplicate with the same source, target, and connector
• A connection that creates a cycle

The Start and End nodes cannot be deleted or duplicated. For other nodes, use the context menu to edit, duplicate, disconnect, or delete. Select multiple nodes to align or distribute them, or use Auto layout to arrange the entire graph.

Save, deploy, and redeploy

Saving stores the edited graph. Both Start and End nodes are required for deployment. If either is missing, an error identifies the missing node.

After changing node structure, settings, or connected semantic assets on a running agent, Redeploy required appears. Moving only a node's position does not change the runtime definition and therefore does not require redeployment.

Workflow agents run through events rather than chat. See Deploy an agent for execution methods.
